MIL-E-19141D
3.3.4 Core wire alloy identity. Each end of rod or wire to be spliced
during processing shall be tested for alloy identity (see 4.4.9), except when
splicing is done to repair a wire break without removing the wire from the
process line. Both ends of each coil drawn to finish size shall be tested for
alloy identity (see 4.4.9) prior to cutting into electrode core wire lengths.
3.3.5 Covered electrode alloy identity. When specified (see 6.2.1), the
core wire of each covered electrode shall be tested for alloy identity after
final marking in accordance with 4.4.9.
3.4 Soundness.
The weld metal surface shall be free of porosity visible
to the unaided eye.
3.5 Linear and non-linear indications. Macro-surfaces of specimens
prepared in accordance with 4.4.5 shall meet the acceptance standards for
linear and non-linear indications for class 2 welds as specified in NAVSEA
0900-LP-003-8000 . No lack of bond is permitted.
3.6 Chemical composition of deposited weld metal. Chemical composition
of deposited weld metal shall be as specified in table IV.
TABLE IV.
of deposited weld metal.
Chemical composition
MIL-I-A2c
Element
MIL-I-A2a
0.80
Carbon
0.30
.50-1.60
Manganese
1.25-2.50
Phosphorus
.04
0.04
l 03
Sulfur
l 03
.20-0.65
Silicon
.90
Chromium
.65
1.50-3000
----
Molybdenum
.70
Single values are maximum percentages.
3.7 Hardness. The hardness of deposited weld metal shall be 200 to 300
Brinell for MIL-I-A2a and 400 to 600 Brinell for MIL-I-A2c.
4.
QUALITY ASSURANCE PROVISIONS
4.1 Responsibility for inspection. Unless otherwise specified in the
contract or purchase order, the contractor is responsible for the performance
of all inspection requirements as specifed herein. Except as otherwise speci- "
fied in the contract or purchase order, the contractor may use his own or any
other facilities suitable for the performance of the inspection requirements
specified herein, unless disapproved by the Government. The Government re-
serves the right to perform any of the inspections set forth in the specifi-
cation where such inspections are deemed necessary to assure supplies and
services conform to prescribed requirements.
.
6
