3.5 Chemical composition of deposited weld metal. Chemical composition testing of deposited weld metal
TABLE IV. Chemical composition (percent) of deposited weld metal. 1/
MIL-8018-C3
MIL-9018-M
MIL-11018-M
Element
MIL-7018-M
MIL-8018-C3SR
0.07 2/
Carbon
0.10
0.12
0.10
Manganese
0.40 to 1.60
0.40 to 1.25
0.60 to 1.25
1.30 to 1.80
Silicon
0.80
0.80
0.80
0.60
Phosphorus
0.030
0.030
0.030
0.030
Sulfur
0.020
0.030
0.030
0.030
Chromium
0.15
0.15
0.15
0.40
Nickel
0.25
0.80 to 1.10
1.40 to 1.80
1.25 to 2.50
Molybdenum
0.35
0.35
0.35
0.25 to 0.50
Vanadium
0.05
0.05
0.05
0.05
Copper
3/
3/
3/
3/
Boron
4/
-----
-----
4/
NOTES:
1/
Single values are maximum percentages.
2/
On sizes of MIL-11018-M electrodes over 3/16 in diameter the maximum carbon content is 0.10 percent.
3/
Use of the suffix RC, e.g., MIL-11018-M RC, indicates that the maximum copper content of the deposited weld
metal shall be 0.15 percent. The remaining basic compositional requirements remain unchanged for the specific
MIL-type. Report copper content for information only for electrodes without the RC suffix.
4/
Report for information.
3.6 Electrode identification. Electrodes shall be identified as specified in MIL-E-22200.
3.6.1 Heat and lot identification. When specified (see 6.2), each electrode shall be marked with heat or lot
identification as specified in MIL-E-22200.
3.7 Electrode lengths. The lengths of electrodes shall be as specified in table V, except for Type MIL-8018-
C3SR, which may be qualification tested in longer lengths (see 6.2).
TABLE V. Electrode lengths.
Sizes
Electrode lengths end-grip
(inches)
(inches)
9, 12, or 14
3
/32 1/
, 5/32, 3/16
14
/32,
¼, 5/16
18
7
NOTES:
1/
See 6.2
3.8 Core wire alloy identity. The core wire alloy identity requirements shall be as specified in MIL-E-22200.
